Cylinders

UK Oval Cylinder eCLIQ. Electronic, optionally available as mechanical (rotary-secured). Splash-proof IP54 as standard. IP55 Dust and rain protection cap available (-WP).

The eCLIQ N534 electronic cylinder combines advanced electronic access control with proven mechanical security, offering a reliable and low‑maintenance solution for demanding environments. Powered entirely by the intelligent eCLIQ key, the N534 requires no batteries or wiring in the door.

Built for high‑security applications, the N534 provides enhanced durability, flexible access management, and audit capability, making it ideal for organisations that need greater control without compromising on robustness.

Profile-double cylinder eCLIQ. Electronic one side, Mechanical (rotary secured) one side.

Brass cylinder housing components.

Standard finish, satin nickel-plated (-SN).

Other finishes available - Polished Brass (PB), Satin Brass (SB), Satin Chrome (SC).

Basic cylinder length 61 mm A/B (Length:30/30) - other installation lengths available - flexible modular system (5mm increments).

Optional, differing basic cylinder length of 56 mm - A/B (Length:28/28).

Both side locking and 360° free-wheeling function as standard. Cam made of break-proof, corrosion-resistant stainless steel. Standard locking cam position 30°; differing locking positions available.

eCLIQ cylinders are maintenance-free.

Splash-proof IP54 as standard.

 IP55 Dust and rain protection cap available for one or both sides (-WP).

Optionally DIN EN 15684 with anti drilling protection class 2 (-AD).

Optionally available with ATEX approval for use in potentially-explosive atmospheres in Zone 1 - II 2G EX IB IIB T4 Gb (-ATEX).

Euro profile-half (single) cylinder eCLIQ. Electronic, optionally available as mechanical (rotary-secured).

Brass cylinder housing components.

Basic cylinder length 30mm - other installation lengths available - flexible modular system (5mm increments).

Free adjustable locking cam set to 45° as standard.

Cam made of break-proof, corrosion-resistant stainless steel.

eCLIQ cylinders are maintenance-free.

Splash-proof IP54 as standard.

IP55 Dust and rain protection cap available (-WP).

Optionally SS504:2024, SS312:2024 for PAS24 Doors and DIN EN 15684 with anti-drilling protection class 2 (-AD).

Optionally available with ATEX approval for use in potentially-explosive atmospheres in Zone 1 - II 2G EX IB IIB T4 Gb (-ATEX.)

These cylinders support flexible permission management, allowing access rights to be updated quickly using electronic keys—without the need to remove or replace the cylinder. Each access event can be recorded, providing valuable audit trails for improved security oversight and accountability. The N530 is ideal for environments where access rights change frequently or where detailed access monitoring is required.

Profile-double cylinder eCLIQ. Electronic one side, Mechanical (rotary secured) one side.

Brass cylinder housing components.

Standard finish, satin nickel-plated (-SN).

Other finishes available - Polished Brass (PB), Satin Brass (SB), Satin Chrome (SC).

Basic cylinder length 61 mm A/B (Length:30/30) - other installation lengths available - flexible modular system (5mm increments).

Optional, differing basic cylinder length of 56 mm - A/B (Length:28/28).

Both side locking and 360° free-wheeling function as standard. Cam made of break-proof, corrosion-resistant stainless steel. Standard locking cam position 30°; differing locking positions available.

eCLIQ cylinders are maintenance-free.

Splash-proof IP54 as standard.

 IP55 Dust and rain protection cap available for one or both sides (-WP).

Optionally DIN EN 15684 with anti drilling protection class 2 (-AD).

Optionally available with ATEX approval for use in potentially-explosive atmospheres in Zone 1 - II 2G EX IB IIB T4 Gb (-ATEX).Profile-double cylinder eCLIQ. Electronic one side, Mechanical (rotary secured) one side.

Brass cylinder housing components.

Standard finish, satin nickel-plated (-SN).

Other finishes available - Polished Brass (PB), Satin Brass (SB), Satin Chrome (SC).

Basic cylinder length 61 mm A/B (Length:30/30) - other installation lengths available - flexible modular system (5mm increments).

Optional, differing basic cylinder length of 56 mm - A/B (Length:28/28).

Both side locking and 360° free-wheeling function as standard. Cam made of break-proof, corrosion-resistant stainless steel. Standard locking cam position 30°; differing locking positions available.

eCLIQ cylinders are maintenance-free.

Splash-proof IP54 as standard.

 IP55 Dust and rain protection cap available for one or both sides (-WP).

Optionally DIN EN 15684 with anti drilling protection class 2 (-AD).

Optionally available with ATEX approval for use in potentially-explosive atmospheres in Zone 1 - II 2G EX IB IIB T4 Gb (-ATEX).

The eCLIQ N352 electronic cylinder delivers intelligent access control while retaining the strength and reliability of a high‑security mechanical cylinder. Powered entirely by the eCLIQ key, it provides advanced functionality without the need for batteries or wiring in the door.

Compact and versatile, the N352 cylinder is ideal for applications where dependable security, flexible access management, and long‑term durability are required.

The eCLIQ N534 electronic cylinder combines advanced electronic access control with proven mechanical security, offering a reliable and low‑maintenance solution for demanding environments. Powered entirely by the intelligent eCLIQ key, the N534 requires no batteries or wiring in the door.

Built for high‑security applications, the N534 provides enhanced durability, flexible access management, and audit capability, making it ideal for organisations that need greater control without compromising on robustness.
