ABLOY
  • Solenoid
  • Standard Stile

EL561 DIN Solenoid Lock

Handle controlled locks are best suited in medium traffic doors. The lock can be switched between fail-locked and fail-unlocked states. The locks can be electrically controlled by access control system or by a remote control system such as timer, keypad or push button. The locks can be used fire rated doors. Both inside and outside handles are electrically controlled. Mechanical opening by cylinder or thumbturn is always possible. Recommended to be used in interior doors of business premises, public buildings, hospitals, educational premises etc. Indications to EAC.

1 of 2

Read in/out.

Microswitch monitoring.

Auto deadlocking.

  • EPD
  • DoP
  • Wiring Diagram
  • Cable Sheet
  • Datasheet
  • Manual
  • EL Cable Chart
  • DoC
  • Brochure
NameValue
HandedField Changeable
ActuatorSolenoid
Forend StyleRadiused
Bolt Projection20
CE CertificationCe certification en 179:N A, Ce certification en 1125:N A, Ce certification en 12209:n a, Ce certification en 14846:0809 CPR 20002737
Mortice StandardDIN
Operating Voltage12-24
Fire Door ApprovalYes
Classification CodesClassification codes en 179:N A, Classification codes en 1125:N A, Classification codes en 12209:N A, Classification codes en 14846:3S5F L611
StandardsEN 14846
ProductProduct IDAttributes
EL561 DIN Solenoid LockEL561-100MM
Backset (mm): 100
EL561 DIN Solenoid LockEL561-55MM
Backset (mm): 55
EL561 DIN Solenoid LockEL561-60MM
Backset (mm): 60
EL561 DIN Solenoid LockEL561-65MM
Backset (mm): 65
EL561 DIN Solenoid LockEL561-80MM
Backset (mm): 80
